880 Chain Curves Tracks Bevel Chains
Material: Polyethylene UHMW-PE Black / Green
Main Application: Conveyor Chain Corner Tracks Guides
Angle: α = 15º ~ 90º
Chain Type: 880-K325, 880-K450 Slat Chains with Dovetail Guide, Side-flex Chain with Bevel Guides
Packing: 2 Pcs/Set
880 Side-flex Chain Curves Tracks Bevel Chains
880 Bevel Side-flex Chain Curve Corner Tracks
Curve Corner Tracks for 880 Chains, bevel machined profiles retain the chains in a mechanical way, with optimal material in UHMWPE - Ultra High Molecular Weight Polyethylene, lower friction and longer guide wearlife
Packaging: The corner tracks are supplied complete with carry and return sections (2 Pieces/Set), Straight tracks are supplied as single profile
880 Bevel Chain Corner Tracks Guides
The track system should be considered in Slat Top Chains composed of tabbed and non-tabbed belts and chains. This is especially important on the return side of the conveyor as this requires different methods of support
880 Bevel Curve Corner Tracks are suitable for 880 Bevel Chains, optional single track or double tracks
